    Eltra · EA58F Profibus

    Eltra EA58F8192B12/28FXX15X3P3R

    − +
    Delivery
    5–10 business days. Express available at additional cost.
    Returns
    14 days. New condition.
    Shipping
    Delivery. DHL, DPD, UPS.
    Description

    Singleturn with blind hollow shaft.
    High resolution rotary encoder.
    Mounting by stator coupling.
    Process Field Bus electrical interface.
    15 mm hollow bore encoder (diameter).
    With aluminium body.

    Characteristics
    Principle of operation absolute
    Revolution type singleturn
    Shaft type blind hollow shaft
    Mounting type stator coupling
    Electronic interface Profibus
    Resolution, ppr 8192
    Power supply, V DC 12…28
    Bore diameter, mm 15
    Enclosure rating IP54
    Max Rotation speed, rpm 3000
    Output type cable glands
    Direction type radial
    Construction size (diam.), mm 58
    Max output frequency 25 kHz LSB
    Operating temperature , °C 0…+60
    Operating temperature , °F +32…+140
    Code Type binary
    Measurement type rotary
    Type of sensor optical
    Weight, g 650
