Eltra EA63A8192B12/28FXX10X3P3R

− +

Delivery

5–10 business days. Express available at additional cost.

Returns

14 days. New condition.

Shipping

Delivery. DHL, DPD, UPS.

Description

Singleturn with solid shaft.
High resolution rotary encoder.
Synchronous flange - 31,75 mm diameter for easy mounting.
Profibus (Process Field Bus) electrical interface.
10 mm shaft encoder (diameter).
Painted aluminium body, stainless steel ball bearings.

Characteristics

Principle of operation absolute

Revolution type singleturn

Shaft type solid shaft

Mounting type synchronous flange

Electronic interface Profibus

Resolution, ppr 8192

Power supply, V DC 12…28

Shaft diameter, mm 10

Enclosure rating IP54

Max Rotation speed, rpm 3000

Output type cable glands

Direction type radial

Construction size (diam.), mm 63.5

Max output frequency 25 kHz LSB

Operating temperature , °C 0…+60

Operating temperature , °F +32…+140

Code Type binary

Measurement type rotary

Type of sensor optical

Weight, g 500
