Eltra EA63D4096B12/28FXX10X6P3R

Name: EA63D4096B12/28FXX10X6P3R
Availability: InStock

€0.00

- +

Description Characteristics

Profibus absolute encoder.
Singleturn with solid shaft.
Centering square flange - diam. 31,75 mm.
Process Field Bus electrical interface.
10 mm shaft encoder (diameter).
Painted aluminium body, stainless steel ball bearings.

Characteristics

Principle of operation absolute
Revolution type singleturn
Shaft type solid shaft
Mounting type centering square flange
Electronic interface Profibus
Resolution, ppr 4096
Power supply, V DC 12…28
Shaft diameter, mm 10
Enclosure rating IP54
Max Rotation speed, rpm 6000
Output type cable glands
Direction type radial
Construction size (diam.), mm 63.5
Max output frequency 25 kHz LSB
Operating temperature , °C 0…+60
Operating temperature , °F +32…+140
Code Type binary
Measurement type rotary
Type of sensor optical
Weight, g 500
