Eltra EA63D720G8/28NP10X3PAR

Optical rotary encoder for factory automation applications.
Singleturn with solid shaft.
Easy setup due to code seset. Reflective optical technology.
Assembly by centering square flange (31,75 mm diam).
10 mm shaft encoder (diameter).
Stainless steel shaft, body form painted aluminium.

Characteristics

Principle of operation absolute
Revolution type singleturn
Shaft type solid shaft
Mounting type centering square flange
Resolution, ppr 720
Power supply, V DC 8…28
Shaft diameter, mm 10
Enclosure rating IP54
Max Rotation speed, rpm 3000
Output type cable
Direction type radial
Construction size (diam.), mm 63,5
Operating temperature , °C 0…+60
Operating temperature , °F +32…+140
Code Type gray
Cable lenth, m 1,5
Measurement type rotary
Type of sensor optical
Weight, g 500
