Eltra EA63E1024G8/28SXX10X3PCR

Optical rotary encoder for factory automation applications.
Singleturn with solid shaft.
Easy setup due to code seset. Reflective optical technology.
50 mm centering square flange for mounting.
Synchronous Serial Interface. It transmits data in a serial mode by using only two signals (DATA and CLOCK), independently from the number of bits of the encoder. It reduce installation costs and simplify the wiring.
10 mm shaft encoder (diameter).
Stainless steel shaft, body form painted aluminium.

Characteristics

Principle of operation absolute
Revolution type singleturn
Shaft type solid shaft
Mounting type centering square flange
Electronic interface SSI
Resolution, ppr 1024
Power supply, V DC 8…28
Shaft diameter, mm 10
Enclosure rating IP54
Max Rotation speed, rpm 3000
Output type cable
Direction type radial
Construction size (diam.), mm 63,5
Max output frequency 100 kHz - 1 MHz
Operating temperature , °C 0…+60
Operating temperature , °F +32…+140
Code Type gray
Cable lenth, m 1,5
Measurement type rotary
Type of sensor optical
Weight, g 500
