Eltra EH88PE720Z5/28L40X3PR2

EH88PE720Z5/28L40X3PR2

Cost effective encoder in aluminium housing for asynchronous motors.
With through hollow shaft.
Suitable for stage machinery and elevators.
Mounting with spring.
Line driver electrical interface. It is perfect to use in cases when the encoder is far from the receiver system or in enviroments exposed to electrical disturbances. Disturbances are limited because of receiver and Data trasmiter work on two complementary channels.
With zero pulse.
40 mm hollow bore encoder (diameter).
Shaft from stainless steel.

Characteristics
  • incremental
  • through hollow shaft
  • with spring
  • line driver
  • 720
  • +
  • 5…28
  • 40
  • IP54
  • 3000
  • cable
  • radial
  • 88
  • 105 kHz
  • -30…+85
  • -22…+185
  • 2
  • rotary
  • optical
  • 350
