EL48C60Z8/24L8X6PR

Encoder for servo motors.
With blind hollow shaft.
Replaceable with Resolver 19 size.
Mounting by stator coupling.
Differential Line Driver encoder. It is perfect to use in cases when the encoder is far from the receiver system or in enviroments exposed to electrical disturbances. Disturbances are limited because of receiver and Data trasmiter work on two complementary channels.
With zero pulse.
8 mm hollow bore encoder (diameter).
Application: AC servomotors and feedback control systems.
Housing material: nickel plated brass. 2 ball bearings from aluminium.

Characteristics
  • incremental
  • blind hollow shaft
  • stator coupling
  • line driver
  • 60
  • +
  • 8…24
  • 8
  • IP40
  • 6000
  • cable
  • radial
  • 48
  • 150 kHz
  • -20…+85
  • -4…+185
  • 0,3
  • rotary
  • optical
  • 100
