EMI63A100S8/24L10S3PR

Robust magnetic encoder with seperated chambers.
With solid shaft.
Suitable for harsh applications with requirements in temperature resistance.
Mounting by synchronous flange (31,75 mm).
Line driver output. It is perfect to use in cases when the encoder is far from the receiver system or in enviroments exposed to electrical disturbances. Data trasmiter and receiver work on two complementary channels so disturbances are limited.
Without zero pulse.
10 mm shaft encoder (diameter).
Sturdy aluminium housing.

Characteristics
  • incremental
  • solid shaft
  • synchronous flange
  • line driver
  • high temperature resistance
  • 100
  • -
  • 8…24
  • 10
  • IP66
  • 3000
  • cable
  • radial
  • 63,5
  • 205 kHz
  • -25…+100
  • -13…+212
  • 0,5
  • rotary
  • magnetic
  • 350
