Name: ER30E360Z5/28P6X3PA
Availability: InStock

With solid shaft.
360 rotary encoder.
Mounting by clamping flange.
PUSH-PULL electrical interface. Due to complementary transistor it is possible to use encoder with longer cable connections and optimal data trasmission even at high working speed.
With zero pulse.
Ideal for application in small devices.
Housing material: PA66 glass fiber reinforced. 2 ball aluminium bearings.

Characteristics

Principle of operation incremental
Shaft type solid shaft
Mounting type clamping flange
Electronic interface push pull
Special features miniaturized
Resolution, ppr 360
Zero pulse +
Power supply, V DC 5…28
Bore diameter, mm 6
Enclosure rating IP54
Max Rotation speed, rpm 3000
Output type cable
Direction type axial
Construction size (diam.), mm 30
Max output frequency 220 kHz
Operating temperature , °C -25…+85
Operating temperature , °F -13..+185
Cable lenth, m 0,5
Measurement type rotary
Type of sensor optical
Weight, g 70

Eltra ER30E360Z5/28P6X3PA
