ETMR1024S8/24L38S8PR0,5+M.035+870+XXX

Non contact ring magnetic encoder. High protection level (IP67) and resistance to vibrations.
With through hollow shaft.
Compact size with 11 mm thickness.
Through hollow ring mounting.
Line driver electrical interface. It is perfect to use in cases when the encoder is far from the receiver system or in enviroments exposed to electrical disturbances. Data trasmiter and receiver work on two complementary channels so disturbances are limited.
Without zero pulse.
Big hollow bore: 38 mm diam.
Excellent solution for use in harsh environments.
Anodized aluminium sensor body and stainless steel magnet actuator.

Characteristics
  • incremental
  • through hollow shaft
  • with star-ring
  • line driver
  • heavy duty
  • 1024
  • -
  • 8…24
  • 38
  • IP67
  • 8000
  • cable
  • radial
  • 350 kHz
  • -20…+85
  • -4…+185
  • 0,5
  • rotary
  • magnetic
  • 100
