Eltra EVCS100S5/28P6PR

Name: EVCS100S5/28P6PR
Availability: InStock

€0.00

- +

Description Characteristics

Electronic handwheel with 40 mm fixing flange screw holes.
Mounting by fixing flange screw holes.
PUSH-PULL electrical interface. Due to complementary transistor it is possible to use wheel with longer cable connections and optimal data trasmission even at high working speed.
Without zero pulse.
6 mm shaft encoder (diameter).

Characteristics

Mounting type fixing flange screw holes
Electronic interface push pull
Resolution, ppr 100
Zero pulse -
Power supply, V DC 5…28
Shaft diameter, mm 6
Output type cable
Direction type radial
Max output frequency 150 kHz
Operating temperature , °C -10…+60
Operating temperature , °F +14…+140
Cable lenth, m 0,3
Weight, g 150
