Eltra EAMW58B12/12G8/30SPZE6XXPR

EAMW58B12/12G8/30SPZE6XXPR

Robust encoder with high IP level.
Multiturn with solid shaft.
Multi turn/single turn resolution: 12 bit/12 bit.
Mounting by synchronous flange (diam. 50mm).
SSI electrical interface. This interface transmits data in a serial mode by using only two signals (DATA and CLOCK), independently from the number of bits of the encoder. It reduce installation costs and simplify the wiring.
With positive logic.
6 mm shaft encoder (diameter).
Perfect for applications in harsh environmental conditions.

Characteristics
  • absolute
  • multiturn
  • solid shaft
  • synchronous flange
  • SSI
  • 8…30
  • 6
  • IP67
  • cable
  • radial
  • 58
  • 100 kHz - 1 MHz
  • -20…+85
  • -4…+185
  • 12 bit
  • 12 bit
  • gray
  • 0,5
  • rotary
  • magnetic
  • 350
